40x40mm very Small Size Glass double edging polishing machine for flat edge working

FOB Reference Price:Get Latest Price
$35,000.00 - $40,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
JF
Max. Glass Size:
1000mm
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Machine Type:
Glass Edging Machine
Production Capacity:
0.5-8m/min
Power(W):
22kw
Certification:
CE, CE
After-sales Service Provided:
Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Global Jinfeng
Voltage:
220V/380V/415V
Dimension(L*W*H):
3000x2750x1200mm
Weight:
3500kg
Type:
Straight line
Glass thickness:
3mm~12mm
Glass parallel error:
≤0.2mm / m
Diagonal error:
≤0.5mm / m
Glass chamfer width error:
≤0.2mm / m
Working table height:
900mm ± 20mm
Glass chamfer width:
1mm
Maximun size:
1000mm
Minimum size:
50mm
Supply Ability
Supply Ability:
20 Set/Sets per Month 200 sets each year
Packaging & Delivery
Packaging Details
plastic paper or strong package or according to customer's requirement
Port
shenzhen/shunde/gaungzhou
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 To be negotiated
Video Description

40x40mm very Small Size Glass double edging polishing machine for flat edge working

******************************************************************************

This machine is specially designed for small glass edge grinding and polishing of 50*50mm / 40*40mm / 38*38mm



Global jinfeng glass machinery Co., LTD is a specialized research and development production glass processing equipment of the high-tech enterprise, with a group of glass processing to the research, development, and production of high quality management personnel and research and development personnel, with rich production experience, strong technical force, excellent processing equipment.
 The company specialized production line current glass double edge grinding and polishing machine,glass tempering machine, glass bending machine, glass straight line vertical grinding machine, glass vertical horizontal sandblast machines, glass washing machines, glass drilling machine, glass bilateral doubleedge grinding machine, glass linear circular edge bilateral edge grinding machine series product, the product specification is complete, the maximum satisfy customer personalized requirements.



Technical Parameters



Glass thickness                                   3mm~12mm

Glass drive speed                               1m/min~4m/min

Maximun size                                       1000mm

Minimum size                                       50mm

Glass parallel error                              ≤0.2mm / m

Diagonal error                                     ≤0.5mm / m

Glass chamfer width error                  ≤0.2mm / m

Glass chamfer width                           1mm

power                                                    22KW

Maximum grinding edge              2mm

Maximum cutting edge                       1mm

Working table height                           900mm ± 20mm

Machine size                                        3000x2750x1200mm

Machine weight                                    3500KG















1.sample

we can make the sample for every client as your requirement.



2.technology

 we had concentrate on glass machine for 10 years at least,we can  unlimited support you if you need.



3. custom-made

we can make as the customer need.our target is -- satisfy all the guests.

4.certification
we had passed CE certificte,also can supply other certifications if you need.
